Skycreat Motor 65161 6000W for Electric surfboard/Hydrofoil/Foilsurf/Surffoil/RC Boat/Esurf/Jetski,/Jetboard, etc

SKU:Fl-PC-65161P02

65161 Motor Spec

• Voltage: 6-20S (25.2-84V)
• Rated Power: 3000W；Max Power: 6000W
• Rated Current: 60A；Peak Current: 200A
• Rated Torque: 6.3 N·m；Max Torque at 60%: 9 N·m
• Max Spin Speed (RPM): 16380
• Dimensions: D65*L161mm
• Max Working Temperature: 120°C
• Insulation Voltage & Leak Current: AC 500V / 1mA / 3s
• Lead Wires Extension: 8AWG × 1300mm
• Waterproof Level: IP68
• Weight: 3kg
• Plug: 8.0mm bullet plug
• Motor Wires: 3 × 8AWG (6.5mm)
• Resistance: 58mΩ
• Shaft: Ø12 -0.005/-0.01mm
• Number of Slots & Poles: 18N / 6P (Please set as 3 pairs when do setup)
• Inductance: 170μH

ESC spec

• ESC model:75200 Pro V2.0With Water Cooling Enclosure

• Voltage: 14-84V (safe for 4-20S)
• Continuous current: 50V/200A; 75V/150A (Values depend on the mounting, ambient temperature and air/water circulation around the device!);
• Burst: 300A
• BEC: 5V@1A
• Support Modes: DC, BLDC, FOC (sinusoidal)
• ERPM: 150000
• Communication Ports: USB, CAN, UART
• Input Source Support: PPM, ADC, UART
• Supported Sensorless: Yes
• Regenerative capacity: Yes
• Programmable via VESC_TOOL: Yes
• 75200 Size:130x67.7x40.1mm(Including alu. case)
• Motor/power wire size: 8 AWG

12MM ROUND WITH THREAD:
