Skycraet F30 Electric Inflatable Float Platform, equipped with a set of 65121 electric outboard motor, safe load capacity 200KG

Skycraet F30 Electric Inflatable Float Platform, equipped with a set of 65121 electric outboard motor, safe load capacity 200KG

$2,054.31 USD
$2,054.31 USD
Sale Sold out
Shipping calculated at checkout.

SKU:Fl-FP-65121F30.

Spec:

  • Safe load: 200KG
  • Hull material: environmentally PVC
  • Product Category: Inflatable Paddle Board

65121 Motor Spec:

  • Voltage range: 6-20S (25.2-84V)
  • Max power: 3700W; Continuous power: 2000W
  • Peak current: 100A;
  • Motor KV: 130KV
  • Size: OD65*L121mm
  • Shaft diameter: 12mm*m8
  • Max output torque:5.5N*M
  • Waterproof rate: IP68
  • Connectors:8mm plug
  • Weight:1.62KG
  • Structure:18N/6P
  • Lead wires extension: 8AWGx1400mm

Battery box parameters

  • Battery outer box size: 371*269*186mm
  • Waterproof grade: IP67
  • Battery box material: ABS
  • Voltage:50.4V
  • Cell specifications: Molicel P42A 27100
  • Battery capacity: 12S 4P 16.8AH/846.72WH/16800mah.
  • Environment: (-20 degrees Celsius + 50 degrees Celsius)
  • Charger: 50.4V 5.5A
  • Charging time: about 2.6 hours


ESC

  • ESC model:75100 pro v2.0
  • Maximum discharge current: Maximum continuous 100A
  • Voltage Range: 6-20s (25.2*84v)
  • Heat dissipation method: water cooling (water pipe outer diameter 8MM, inner diameter 3MM)
  • Support control protocols ppm, uart, adc, pas
